Deadbolt Installation

A deadbolt works by throwing a solid steel bolt deep into the door frame's strike plate — typically at least one inch, and up to 1.5 inches on ANSI Grade 1 hardware like Schlage B-series or Kwikset SmartKey models. That throw length is what makes a deadbolt fundamentally different from a spring latch: it cannot be slipped with a credit card or shimmed open by manipulating the latch face. But the bolt is only as strong as the strike plate and the door frame around it. A common oversight during DIY installation is using the short screws that come in the box — usually half-inch or three-quarter-inch fasteners that anchor only into the door casing, not the structural stud behind it. Our technicians install strike plates with three-inch screws that reach the stud, which dramatically increases kick-in resistance. That attention to the full system — not just the lock cylinder — is what separates a professional deadbolt installation from a hardware-store afternoon project.

Older homes in Elkins Park, many of which were built in the early to mid-twentieth century, often have non-standard door thicknesses, mortised lock pockets already cut into the stile, or decorative trim that makes off-the-shelf cylindrical deadbolts a poor fit. In those situations, a mortise lock is frequently the correct solution. A mortise lock body sits inside a recessed pocket in the door edge, combining deadbolt, latch, and sometimes a nightlatch into a single case. It distributes force across a larger section of the door stile and is significantly harder to defeat through brute force. McKinley Locksmith carries mortise lock hardware sized for residential and light-commercial doors and can cut the mortise pocket cleanly without splitting or cracking the door stile.

Our mobile units are stocked with the tooling and lock hardware to handle most deadbolt jobs on the first visit. When we arrive, the technician assesses the door material, thickness, backset measurement (typically 2-3/8" or 2-3/4"), the condition of the existing bore hole, and the alignment of the door in its frame. A door that's dropped on its hinges or has swollen from moisture will cause a deadbolt to bind or fail to throw fully — issues that a visual inspection catches before the new hardware goes in. We address frame and alignment problems as part of the job rather than leaving them as a hidden cause of premature lock failure.

Where a new bore hole is needed — for example, when converting from a knob-only door or adding a second deadbolt — we use hole saws and chisels sized to the specific lock body, working carefully to avoid tearout on decorative or painted door faces. Damage-free work is our goal on every visit: we don't rush the prep, and we don't force hardware that doesn't fit cleanly. Once the deadbolt body, cylinder, and strike plate are fitted and torqued, we test the throw action, check key operation in both directions, and verify that the bolt seats squarely in the strike box without dragging. The job isn't complete until the lock operates smoothly and you're satisfied with the result. If you're ready to schedule or want to talk through your options first, call us now at 267-497-3060 — we answer every hour of the day, every day of the year.

We also handle emergency locksmith situations where a door lock has been damaged in a break-in attempt, a key has snapped in the cylinder, or a tenant has moved out and the exterior locks need to be rekeyed or replaced immediately. In those cases, the same mobile team that does planned installations responds — no separate emergency crew, no waiting for a morning shift.
